In the Load settings box you can chose to include the load or not.

The first option will cascade all the components into one single Touchstone block whereas the second option will create a Touchstone block for each components. In the last case the results may differ between CST and BetaMatch due to differences between ideal and measured components. The Network Settings gives the choice between using Touchstone files for the components (which will give exactly the same results) or to convert the components into ideal equivalent components. The CST Export window is opened by selecting File Menu –> Export and Open in CST Design Studio.: The matching network can be exported back to CST a new Design Studio canvas in a few different formats.
